Focus on the details丨Using failure analysis to find the crux of production problems

Release time:

2023-11-27 17:42

Source:

Electronic component failure is defined as complete or partial loss of function, parameter drift, or intermittent occurrence of the above conditions. Electronic component analysis is an after-the-fact check of a failed component. As needed, electrical testing and necessary physical, metallurgical and chemical analysis techniques are used to verify the reported failure, confirm the failure mode and identify the failure mechanism.

The main objects of analysis include semiconductor discrete devices such as resistors, capacitors, inductors, connectors, MOS, relays, diodes, transistors, SCRs, etc., integrated circuits of various sizes and package forms, RF and microwave devices, power modules, optoelectronic modules and other components and modules.

I. Case background

The customer has a batch of sold stock chips, the buyer uses the batch of chips for production operations, PL-2 power failure, flame failure, no light or key failure phenomenon, and the defective rate is as high as 60%. In order to find out the problem, the PCB board was tested with a jig, and it was found that some of the boards needed to be powered off 4-6 times before the phenomenon occurred.

Then, the buyer removed the microcontroller on the normal PCB assembly and switched it to the defective PCB assembly, and the function of the PCB assembly returned to normal.

The IC removed from the defective PCB assembly was still NG when the program was re-programmed, so the buyer guessed that the quality of the microcontroller was the problem.

Therefore, the buyer returned the batch of products, the customer in order to confirm the cause of production failure is caused by the chip itself, commissioned us to assist in analyzing the cause of failure.

Analysis process

1.Appearance analysis

Appearance test on the failed sample provided by the client to confirm whether there are obvious abnormalities on its surface.

Test results: From the appearance of the defective samples, no breakage phenomenon is found, and no microcontroller screen printing ghosting, blurring and other problems.
